Tmax Musclelift Winch 6500 24V

€398.24 tax incl.
(zawiera VAT 23%)
Log in as a company by purchasing without 23% VAT - applies to companies outside Poland
€323.78 tax excl.
The price has not changed
The price has not changed

Quantity
Magazyn wysyłkowy - dostępnych jest: 6
Sklep stacjonarny - dostępnych jest: 6
In Stock

No queries yet, leave the first!
  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

ParameterValue
Maximum Pulling Capacity (single line)6500 lbs (2948 kg)
Gear Ratio161:1
Motor6 HP, DC, Series Wound 24V
ControlWired remote control
Gearbox3-stage planetary gear
ClutchSliding ring gear
BrakeAutomatic, internal – in drum
DrumDiameter 63.5 mm x Length 135 mm
CableSteel 24 m x 7 mm
Cable GuideRollers
Remote Control
Recommended Battery650 CCA
Net Weight29 kg
Overall Dimensions (LxWxH)441 x 160 x 1196 mm
Mounting Bolt Pattern166.4 x 114.3 mm

Line Speed and Current Draw – First Layer

Load (lbs / kg)0 / 01500 / 6803000 / 13614500 / 20416000 / 27216500 / 2948
Line Speed (feet/minute)45.2622.9620.3417.7113.1212.46
Line Speed (m/minute)13.876.25.443.8
Current Draw (A)5381110138162172
Tmax Musclelift Winch 6500 24V Tmax Musclelift Winch 6500 24V Tmax Musclelift Winch 6500 24V Tmax Musclelift Winch 6500 24V
7310104

Data sheet

MAX LINE PULL
GEAR REDUCTION RATIO
VOLTAGE
24V
Rope
Stalowa
